Grade 2 Titanium Rectangular Bar

When you need superior strength and reliability for your most demanding applications, our grade 2 titanium rectangular bar delivers exceptional performance.  Our rectangular bars are precision-machined to exact specifications, ensuring you get consistent quality every time. With over 30 years of experience in the rare metal industry, we understand your requirements for high-performance materials that won't compromise on quality.

Key Features and Benefits

Our Grade2 rectangular bars offer remarkable advantages for your projects:

• Lightweight Design: 40% lighter than steel while maintaining exceptional durability
• Corrosion Resistance: Withstands harsh environments including seawater and industrial chemicals
• Temperature Stability: Performs reliably from cryogenic conditions up to 600°F (316°C)
• Excellent Machinability: Easy to work with using standard machining techniques
• Biocompatibility: Safe for medical and food-grade applications

Specifications Chart	ASTM B348/ ASTM SB348
Dimensions	Customized
Length in mm	<= 3000 mm
Surface Finish	Black, Bright Polished, sandblasting
Form	Round, Square, Hex (A/F), Rectangle, Billet, Ingot, Forging Etc.
Certificate	ISO 9001:2015
Production time	Normal time need about 10-15 working days

Available Grades and Materials

 we also offer other titanium grades to meet your specific needs:

• Grade 2: Commercial pure titanium for excellent formability
• Grade 5 (Ti-6Al-4V): The common titanium alloy
• Grade 23 (Ti-6Al-4V ELI): Extra low interstitial for medical applications

	N	C	H	Fe	O	Al	V	Pa	Mo	Ni	Ti
Gr 1	0.03	0.08	0.015	0.20	0.18	/	/	/	/	/	bal
Gr 2	0.03	0.08	0.015	0.30	0.25	/	/	/	/	/	bal
Gr 5	0.05	0.08	0.015	0.40	0.20	5.5~6.75	3.5~4.5	/	/	/	bal

Grade	Mechanical properties at room temperature, not less than
	tensile strength	Yield Strength	Elongation	percentage reduction of area
GR1	240 MPa	170MPa	25%	30%
GR2	345MPa	275MPa	20%	30%
GR5	895MPa	825 MPa	10%	20%

Manufacturing Process

Our precision manufacturing process ensures consistent quality:

1. Raw Material Selection: We source only the highest grade titanium alloys
2. Hot Forging: Improves material structure and eliminates defects
3. Precision Machining: CNC machining to exact dimensional tolerances
4. Heat Treatment: Optimizes mechanical properties for your application
5. Quality Testing: Comprehensive inspection before shipment

​​​​​	​​​​​	​​​​​	​​​​​
​​​​​	​​​​​	​​​​​	​​​​​

Applications and Industries

Your industry demands the best, and our rectangular bars deliver:

Aerospace: Aircraft components, engine parts, landing gear

Medical: Surgical instruments, orthopedic implants, dental applications

Marine: Propeller shafts, hull components, offshore equipment

Automotive: High-performance engine components, exhaust systems

Chemical Processing: Reactor vessels, heat exchangers, piping systems

Product Dimensions and Tolerances

Available Sizes:

• Width: 15-100mm
• Thickness: 3-40mm
• Length: Up to 6000mm
• Custom dimensions available upon request

Tolerances:

• Dimensional accuracy: ±0.1mm
• Surface finish: Ra 1.6μm or better
• Straightness: ±0.5mm per meter

Product Features in Detail

Fatigue Resistance: Your applications face repeated stress cycles. Our Ti-6Al-4V alloy maintains integrity through millions of cycles, making it perfect for dynamic loading conditions.

Weldability: Need to join components? Our material welds beautifully using GTAW or GMAW processes with proper techniques.

Heat Treatment Response: You can enhance properties further through controlled heat treatment, achieving optimal hardness and strength for your specific application.

Quality Assurance and Testing

Every grade 2 titanium rectangular bar undergoes rigorous testing:

• Chemical composition analysis
• Mechanical property verification
• Dimensional inspection
• Surface quality assessment
• Non-destructive testing when required

Our quality management system ensures you receive materials that meet or exceed specifications every time.

OEM & Customization Services

We understand your projects have unique requirements. Our customization services include:

• Custom dimensions and tolerances
• Specialized heat treatments
• Surface finishing options
• Small quantity prototyping
• Large volume production runs

Packaging and Shipping

Your materials arrive safely and ready to use:

• Protective packaging prevents damage during transit
• Clear labeling with material certificates
• Worldwide shipping to over 50 countries
• Flexible delivery options to meet your timeline​​​​​​​

​​	​​	​​	​
​​	​​	​​	​​

Why Choose Us

Located in China's "Titanium Capital," we bring you:

• 30+ Years Experience: Deep industry knowledge and expertise
• Global Reach: Successfully serving customers in 50+ countries
• Quality Focus: Customer-first approach with continuous improvement
• Competitive Pricing: Cost-effective solutions without compromising quality
• Reliable Partnership: Trust, honesty, and on-time delivery

​​​​​

​​​​​

​​​​​

​​​​​

​​​​​

​​​​​

FAQs

Q: What's the minimum order quantity?

A: We accommodate both small prototype orders and large production runs. Contact us for specific requirements.

Q: Can you provide material certificates?

A: Yes, we provide complete material certificates with chemical composition and mechanical properties.

Q: What's the typical lead time?

A: Standard sizes ship within 7-10 days. Custom orders typically require 1-2weeks.

Q: Do you offer technical support?

A: Absolutely! Our experienced team provides technical guidance for material selection and application requirements.

Contact Us

Ready to experience the superior performance of our grade 2 titanium rectangular bar? Our team is here to help you find the perfect solution for your application.

Email: info@chdymetal.com

Contact us today for a quote, technical consultation, or to discuss your specific requirements. We're committed to providing you with exceptional materials and service that exceed your expectations.
