grade 5 titanium plate

 Product Introduction

Grade 5 titanium plate is commonly purchased as raw material for machining structural parts, equipment components, and other products that require high strength without excessive weight. Known as Ti-6Al-4V, this alloy contains aluminum and vanadium, giving it considerably higher strength than commercially pure titanium.

For buyers, choosing the right Grade 5 plate involves more than confirming the material grade. Plate thickness, material condition, dimensional tolerance, and the amount of machining required can all affect the suitability of the material.

CHDY supplies Grade 5 titanium plates for industrial customers. We can check available plate sizes, cutting requirements, and material documentation based on your order specifications.

Key Features and Benefits

Our titanium alloy plates offer remarkable advantages for your projects. You'll benefit from an outstanding strength-to-weight ratio that reduces overall component weight while maintaining structural integrity. The excellent corrosion resistance ensures long-lasting performance in harsh environments, including marine and chemical applications.

The low thermal expansion properties make these plates ideal for precision applications where dimensional stability matters. You'll also appreciate the superior fatigue resistance, which extends component lifespan under cyclic loading conditions. The biocompatibility of Ti-6Al-4V makes it perfect for medical implants and surgical instruments.

Technical Specifications

• Alloy Composition: Ti-6Al-4V (90% Ti, 6% Al, 4% V)
• Density: 4.43 g/cm³
• Tensile Strength: 895-960 MPa
• Yield Strength: 830-895 MPa
• Elastic Modulus: 114 GPa
• Thickness Range: 1-50mm
• Standard Compliance: ASTM B265, AMS 4911

What Makes Grade 5 Different from Commercially Pure Titanium?

Grade 5 is not a commercially pure titanium grade. It is an alloy developed to provide substantially higher mechanical strength.

The addition of aluminum and vanadium changes the material's structure and mechanical behavior. As a result, Grade 5 is frequently selected for load-bearing components rather than applications where easy forming is the main consideration.

Its relatively low density also makes it useful when component weight must be controlled.

However, higher strength does not automatically make Grade 5 the best choice for every application. Commercially pure titanium may be more suitable for parts requiring extensive cold forming or particular corrosion performance.

Available Grades and Materials

We specialize in Ti-6Al-4V grade 5 titanium plate manufacturing, offering various surface finishes and conditions. You can choose from annealed, solution treated, or aged conditions based on your specific requirements. Our plates are available in both alpha-beta and beta annealed conditions to optimize mechanical properties for your application.

Manufacturing Process

Our experienced team uses advanced manufacturing techniques to produce consistent, high-quality plates. We start with premium titanium ingots and employ controlled rolling processes to achieve precise thickness tolerances. Heat treatment processes are carefully controlled to optimize mechanical properties and microstructure.

Quality control measures throughout production ensure every plate meets your specifications. Our 30+ years of industry experience guarantees reliable manufacturing processes that deliver consistent results.

​​​​​

Raw material inspection

​​​​​

Titanium Melting

​​​​​

Titanium forging

​​​​​

Machining and forming

​​​​​

Final inspection

​​​​​

Packaging

​​​​​	​​​​​	​​​​​	​​​​​
​​​​​	​​​​​	​​​​​	​​​​​

Where Grade 5 Titanium Plate Is Used

Machined Structural Components

Grade 5 plate is often used as starting material for components that require high strength and controlled dimensions.

These may include brackets, mounting components, and other structural parts.

Industrial Equipment Parts

Ti-6Al-4V plate can be used for equipment components where its mechanical properties and relatively low weight provide an advantage.

Marine Engineering

Grade 5 titanium may be selected for certain marine components requiring strength and corrosion resistance.

The suitability of the material should be assessed according to the operating environment and contact with other metals.

Aerospace Material Supply

Ti-6Al-4V is widely used in aerospace applications.

However, material intended for aerospace components may require specific specifications, testing, traceability, and supplier approval.

Engineering Development

Grade 5 plate is also purchased for prototype components, material testing, and engineering development projects.

Be used in a wide range of industries.



​​​​​

Marine engineering

​​​​​

Medical implants

​​​​​

Medical Equipment

​​​​​

Chemical Processing

​​​​​

Aerospace and Defense

​​​​​

Energy and Environmental Engineering

Product Dimensions and Tolerances

We maintain strict dimensional tolerances to ensure your components fit perfectly. Standard thickness tolerances range from ±0.1mm for thin plates to ±0.5mm for thicker sections. Length and width dimensions can be customized according to your requirements, with typical tolerances of ±2mm.

Surface finish options include mill finish, pickled, or polished surfaces depending on your application needs.

Inspection and Material Traceability

Material verification is particularly important when Grade 5 titanium plate will be used for mechanical components.

Depending on the purchase specification, customers may require confirmation of:

Chemical Composition

Verification that the material meets the specified alloy chemistry.

Mechanical Properties

Tensile and yield strength results, where required by the applicable standard.

Dimensions

Inspection of plate thickness, width, length, and any agreed tolerances.

Material Identification

Heat or batch identification to support traceability.

Surface Condition

Confirmation of any agreed surface or visual inspection requirements.

Additional testing or documentation should be discussed before ordering.

Product Features in Detail

The unique microstructure of our grade 5 titanium plate provides exceptional mechanical properties. The alpha-beta phase structure delivers optimal strength while maintaining good ductility for forming operations. Low density characteristics reduce component weight by up to 40% compared to steel alternatives.

Excellent weldability allows for complex fabrication processes without compromising joint integrity. The material's non-magnetic properties make it suitable for electronic and scientific applications where magnetic interference must be avoided.

Quality Assurance and Testing

Every plate undergoes comprehensive testing including chemical composition analysis, mechanical property verification, and dimensional inspection. We provide certified test reports with each shipment, documenting compliance with relevant standards.

Our quality management system ensures consistent product quality and traceability throughout the manufacturing process. Ultrasonic testing identifies any internal defects, guaranteeing structural integrity.

OEM & Customization Services

We understand that your projects may require specific dimensions or properties. Our technical team works closely with you to develop customized solutions that meet your exact requirements. From special alloy compositions to unique surface treatments, we can adapt our manufacturing processes to deliver the perfect solution.

Packaging and Shipping

Careful packaging protects your plates during transportation. We use appropriate cushioning materials and moisture barriers to prevent damage or contamination. Our logistics team coordinates worldwide shipping to over 50 countries, ensuring timely delivery to your facility.

​​	​​	​​	​
​​	​​	​​	​​

Why Choose Us

Located in China's "Titanium Capital," we combine decades of expertise with state-of-the-art manufacturing capabilities. Our founder's 30+ years in the rare metal industry ensures you receive products backed by extensive knowledge and experience.

We focus on competitive pricing, on-time delivery, and customer-focused service. Our commitment to continuous improvement means you'll always receive the latest technological advances and manufacturing innovations.

​​​​​

​​​​​

​​​​​

​​​​​

​​​​​

​​​​​

FAQs

Q: What's the difference between Grade 2 and Grade 5 titanium?

A: Grade 5 offers significantly higher strength but lower corrosion resistance compared to pure Grade 2 titanium.

Q: Can you provide custom thickness options?

A: Yes, we can manufacture plates from 1mm to 50mm thickness according to your specifications.

Q: What certifications do you provide?

A: We provide mill test certificates documenting chemical composition, mechanical properties, and dimensional compliance.

Contact Us

CHDY supplies titanium and other rare metal materials to customers in different industries.

Our titanium product range includes plates, sheets, bars, wires, and tubes in commercially pure and alloy grades.

For Grade 5 titanium plate orders, we can help check available material sizes, specifications, and documentation based on customer requirements.

Whether you need full plates or smaller cut pieces for machining, please send us the dimensions and quantity for a quotation.
