niobium metal foil

Product Introduction

Niobium metal foil is a thin niobium product used in applications where corrosion resistance, high-temperature stability, and good ductility are required. It can be supplied in different thicknesses and widths according to the application and processing requirements.

Niobium foil is available in commercially pure grades and can also be supplied according to specific material specifications. For applications requiring high purity or special material properties, the required grade and chemical composition should be confirmed before production.

Why Choose Our Premium Niobium Foil Solutions?

Located in Baoji, China's renowned "Titanium Capital," we combine decades of metallurgical expertise with state-of-the-art manufacturing capabilities. Our niobium foil products serve customers across 50+ countries, including the United States, Germany, South Korea, and Singapore.

Material Properties of Niobium Foil

Niobium is a refractory metal with a melting point of approximately 2,477°C. It has good chemical stability and corrosion resistance in many environments.

The material also has good ductility, which makes it suitable for producing thin foil and for applications where the foil needs to be formed or processed further.

Niobium becomes superconducting below its transition temperature of approximately 9.25 K. This property is relevant to superconducting and cryogenic applications.

Important properties of niobium include:

High melting point

Good corrosion resistance

Good ductility and formability

Good chemical stability

Low-temperature superconductivity

Suitable for thin and lightweight components

The actual properties of niobium foil depend on purity, thickness, material condition, and manufacturing process.

Technical Specifications

Property	Specification
Grades Available	Nb 1, Nb 2, R 04200, R 04210
Purity Level	>99.95%
Density	8.5 g/cm³
Standard Compliance	ASTM B 393
Thickness Range	0.2mm (custom thickness available)
Width Options	100mm (custom widths available)
Production Method	Cold Rolled
Minimum Order	1 kg
Delivery Time	10-15 days
Certificate	ISO 9001:2015
Production time	Normal time need 10-15working days
Payment terms	30%TT in advance, 70% balance before shipment

Chemical Composition

Chemistry %
Designation	Chief component		Impurities maximum
	Nb	Fe		Si	Ni	W	Mo	Ti	Ta	O	C	H	N
Nb1	Remainder	0.004		0.003	0.002	0.004	0.004	0.002	0.07	0.015	0.004	0.0015	0.002
Nb2	Remainder	0.02		0.02	0.005	0.02	0.02	0.005	0.15	0.03	0.01	0.0015	0.01

Applications of Niobium Metal Foil

Niobium metal foil is used in a range of technical and industrial applications.

Typical applications include:

Chemical processing equipment

Vacuum equipment

Electronic components

Thin-film and coating applications

High-temperature components

Laboratory and research equipment

Superconducting-related applications

Cryogenic equipment

Specialized metal components

The required niobium grade and foil thickness can vary between applications. The operating environment and final use should therefore be considered when selecting the material.

Quality Assurance & Manufacturing Excellence

We maintain strict quality control throughout our manufacturing process. Our cold rolling technology ensures uniform thickness and superior surface finish. Every batch undergoes comprehensive testing to verify chemical composition, mechanical properties, and dimensional accuracy.

Manufacturing Process

1. Raw Material Selection: High-purity niobium ingots sourced from certified suppliers
2. Cold Rolling: Precision rolling to achieve exact thickness specifications
3. Heat Treatment: Controlled atmosphere processing for optimal properties
4. Quality Testing: Comprehensive inspection including chemical analysis and dimensional verification
5. Custom Finishing: Surface treatments and cutting to your exact requirements

​​​​​	​​​​​	​​​​​	​​​​​
​​​​​	​​​​​	​​​​​	​​​​​

Customization Capabilities

We understand that every application has unique requirements. Our niobium metal foil can be manufactured to meet your specific needs:

• Custom Dimensions: Any thickness, width, and length within our manufacturing capabilities
• Special Grades: Modified compositions for specific performance requirements
• Surface Treatments: Various surface finishes including polished, etched, or coated options
• Packaging Solutions: Protective packaging designed for your handling and storage needs

Technical Support & Customer Service

Our experienced technical team provides comprehensive support throughout your project. From initial consultation to delivery, we ensure you receive the right solution for your application. We offer:

• Material selection guidance
• Application-specific recommendations
• Technical documentation and certificates
• Custom packaging and logistics support

​​​​​

​​​​​

​​​​​

​​​​​

​​​​​

​​​​​

Get Your Custom Quote Today

CHDY supplies niobium metal foil and other niobium products for industrial and technical applications. Different material purities, dimensions, and specifications can be discussed according to the customer's requirements.

For a quotation, please send us the following information:

Required thickness

Width and length

Material purity or grade

Quantity

Applicable standard

Application, if relevant

We will check the material and production options based on your requirements and provide a quotation accordingly.

Contact us today:

Email: info@chdymetal.com

Minimum order: 5 kg

Fast delivery: 10-15 days

Global shipping available
