titanium mesh basket

1. Grade: Gr1,Gr2
2. Size: customized
3. Production method: argon arc welding
Product Description

Titanium Mesh Basket for Electroplating and Anodizing: Custom-Sized Anode Baskets

CHDY is short for Shaanxi Chuanghui Daye Metal Material Co., Ltd. The firm supplies anode holders for finishing lines. One item in that range is the titanium mesh basket, used for electroplating. Anodizing and electrowinning are two other uses. Each basket is made from commercially pure titanium, ASTM B265 Grade 1 or Grade 2. A mesh body sits inside a solid titanium frame. Basket size and mesh opening can be changed to match your tank. Material grade and mounting arrangement can also be adjusted. The technical details are checked first. Send your tank size, anode material and bath details. That way the design can be confirmed with you before you order.

What the Basket Does

In a plating tank, This product holds soluble anode materials. Copper nuggets and nickel balls are two examples. Nickel crowns are used as well. S-rounds work too, and so do tin pellets. The basket does not act as the metal source. It is an inert current carrier. Solution passes through the mesh and reaches the anode pieces inside. Those pieces dissolve. Metal ions in the electrolyte are replenished.

A stable passive oxide film forms on titanium. That is why many plating solutions use it for baskets. Anode pieces kept in a basket also help keep the anode shape more consistent. The anode-to-cathode distance stays steadier as the material is consumed.

Good electrical contact matters. It has to hold between the basket, the hanger and the anode material for the run to stay steady. The solution matters too, and so does the way the cell is run. Basket design plays a part as well.

Main Features

  • Corrosion resistance: A passive oxide film holds up in a lot of chemical environments. Oxidizing acids like nitric and chromic are among them. Before you pick a basket, check the bath chemistry. Look at the temperature too, plus the conditions the cell runs under.
  • Open mesh structure: Solution moves around the anode pieces through the mesh. Small pieces drop through openings that are too big. Flow gets cut back, or the mesh clogs, when the openings are too small.
  • Lower weight: Titanium is less dense than plenty of engineering metals. That can make handling and anode replacement easier. How much weight you actually save comes down to dimensions, mesh thickness and frame design.
  • Custom dimensions: No two tanks are the same size. Baskets can be built to fit your tank space, along with the anode capacity and mounting layout you need.
  • Repeated use: How long a basket lasts comes down to operating conditions, maintenance, electrical contact and exposure to the plating solution. Check it regularly for deformation, damaged mesh or poor connections.

Specifications

Parameter Details
Grade Gr1, Gr2
Main Components Titanium mesh plate, frame plate, hook
Production Method Argon arc welding
Customization Available according to customer drawings
Purity Up to 99.7%
Standards ASTM B265, ASTM B348, ASTM B863
Size Customized
Certificate  ISO9001:2015
Applications

NICKEL PLATING
CHROMIUM PLATING
COPPER PLATING
SILVER PLATING
CADMIUM PLATING
ZINC PLATING
BRASS PLATING
TIN PLATING
ANODISING

chemical industries

Exact dimensions are not listed here. Nor are mesh opening values, weight or thickness. For your project, contact CHDY and the team will confirm them.

Certificationimg-15-15​​​​

Applications

  • Aluminum anodizing: This basket works in Type II (sulfuric) and Type III (hardcoat) lines. There it has to handle acidic conditions and cyclic current loads. Check that it suits your line before you order.
  • Nickel plating: In suitable nickel systems it holds the nickel anode pieces. Choose the design by anode size and tank layout. Your operating conditions count too.
  • Copper plating: Some copper baths work with it, as long as the chemistry matches. Check that the material is compatible first, then pick a basket.
  • Precious metal plating: Gold and platinum baths let you pair the basket with Ti-clad copper contact hooks. Check the bath chemistry first.
  • Medical parts and ultrasonic cleaning: Titanium has no magnetic pull. Check the cleanliness and validation rules in your own quality procedures.
  • Industrial lines and replacement: Used where replaceable soluble anodes are needed, including electrowinning and zinc, tin, copper and nickel plating. For replacement orders, send the original dimensions, photographs or drawings.

What to Confirm Before You Order

Send these details so the design of your titanium mesh basket can be confirmed:

  • Tank size, available space and mounting arrangement
  • Anode material and piece size, which set the mesh opening
  • Bath chemistry, temperature and operating conditions
  • Original drawings, photographs or samples for replacement orders

Titanium suits selected baths only, so bath data matters most.

Customization and Supply

Each this product can be supplied in different sizes and configurations. Dimensions, mesh openings, material grades and mounting arrangements follow your requirements, subject to technical confirmation. Drawings or samples help confirm the fit.

About CHDY for titanium mesh basket

CHDY is based in Baoji High-tech Development Zone, often called China's "Titanium Capital". Its founder has more than 30 years of experience in the rare metal industry, and its products have been supplied to more than 50 countries, including the United States, Germany, South Korea and Singapore. The company works with titanium, tantalum, niobium, tungsten, molybdenum, zirconium, nickel and other rare metal alloys for the metallurgy, electronics, medical and special steel fields.

Packaging

The packing method is confirmed with each quotation, based on titanium mesh basket size and shipping destination.

Be used in a wide range of industries.



Marine engineering​​​​​

Marine engineering

Medical implants​​​​​

Medical implants

Medical Equipment​​​​​

Medical Equipment

Chemical Processing​​​​​

Chemical Processing

Aerospace and Defense​​​​​

Aerospace and Defense

Energy and Environmental Engineering​​​​​

Energy and Environmental Engineering

contact us



N

C

H

Fe

O

Al

V

Pa

Mo

Ni

Ti

Gr 1

0.03

0.08

0.015

0.20

0.18

/

/

/

/

/

bal

Gr 2

0.03

0.08

0.015

0.30

0.25

/

/

/

/

/

bal

Certification​​​​​ Certification​​​​​ Certification​​​​​ Certification​​​​​ Certification​​​​​ Certification​​​​​

ISO Certificate

iso certificate

FAQ

Q: Can titanium baskets be used in all acid baths?

A: No. Titanium holds up well in plenty of oxidizing acids. Nitric and chromic are two of them. Hydrofluoric acid is a different case. The same goes for fluoride solutions at high concentration. Both of them eat away the oxide film. Send your bath data over and we will take a look.

Q: What stops the basket from carrying current?

A: An oxide layer builds up on titanium. That layer can get in the way of electrical contact. Clean the contact points first. Then check that the hanger, basket and anode pieces all sit tight against each other. Once the design is fixed, we can talk through the contact layout.

Q: How long does a basket last?

A: How long a basket lasts comes down to the bath chemistry, the temperature, the current load, maintenance, and the contact condition. Without those details, no fixed lifespan can be given. Check the basket on a regular basis. Look for deformation, damaged mesh or weak connections.

Q: How do I clean a fouled basket?

A: Picking the right method starts with the deposit and the bath. Titanium can be attacked by some chemicals. So before you use anything, check the cleaning method and the immersion time with the supplier.

Q: Which works better, expanded mesh or woven wire?

A: It depends on anode piece size, solution flow and mechanical load. Expanded mesh is a single piece of metal with no loose strands, while woven wire and perforated plate are also available. Send your requirements for a recommendation.

Q: Can I get a basket made to fit my own plating tank?

A: Yes. Size is not fixed. The same goes for mesh openings. Material grade and the way it mounts can change too, but a technical check comes first. Drawings or samples help, send them to info@chdymetal.com.

Contact Us

Send your tank size, anode type and bath details to info@chdymetal.com. That is how we confirm which titanium mesh basket fits.
