Gr2 Titanium Plate

Product Details

Gr2 Titanium Plate is a high-purity commercial titanium product known for its excellent corrosion resistance, ductility, and formability. As a standard material in chemical processing, marine engineering, and industrial applications, it offers a reliable combination of moderate strength and outstanding corrosion protection.

Manufactured in accordance with ASTM B265 and ISO 5832 standards, each plate ensures stable mechanical properties and uniform thickness, making it suitable for large-scale fabrication, pressure vessel construction, and titanium equipment lining.

Technical Specifications

Property	Specification
Grade	Gr2 (Commercially Pure Titanium)
Standard	ASTM B265 / ASME SB-265 / ISO 5832
Thickness Range	0.8 mm – 80 mm
Width Range	100 mm – 2000 mm
Length Range	500 mm – 6000 mm
Density	4.51 g/cm³
Tensile Strength	≥ 345 MPa
Yield Strength	≥ 275 MPa
Elongation	≥ 20%
Surface Finish	Pickled / Bright / Polished / Custom Finish

Gr2 titanium plate has the following performance characteristics:

1.Strength and density: The density of titanium plate is 4.51g/cm ³, which is about half of iron, but its strength is nearly 1.5 times higher than ordinary steel. This makes Gr2 titanium plate an ideal lightweight structural material.

2. Corrosion resistance:  titanium plate has excellent corrosion resistance, can withstand extremely high temperatures and pressures, and will not be corroded by atmospheric environment or most water, acid and alkali solutions. Even in strong corrosive agents such as aqua regia, titanium plates can maintain their stability.

3. Biocompatibility: Gr2 titanium plates are non-toxic, odorless, and non irritating to human tissues, making them widely used in the field of medical device manufacturing, such as artificial joints and dental implants.

4. Processing performance: The processing technology of Gr2 titanium plate is relatively complex, mainly manufactured through two methods: hot rolling and cold rolling. Hot rolling is the process of heating titanium plates to high temperatures and then rolling them, while Cold rolling is carried out at room temperature. In addition, it also includes treatment processes such as annealing and acid washing.

​​​​​​​​​​​​​​Manufacturing & Processing Capability

1. Hot forging is a forging process carried out above the recrystallization temperature of metal.

2. Hot rolling is a rolling process carried out at temperatures higher than the recrystallization temperature.

The rolling process in which the plastic deformation temperature of cold rolling is lower than the recovery temperature.

3. Annealing: A metal heat treatment process in which a metal is slowly heated to a certain temperature, held for a sufficient period of time, and then cooled at an appropriate rate (usually slow cooling, sometimes controlled cooling).

4. Acid washing: Immerse the workpiece in acid to remove oxides and other thin films on the metal surface.

Shaanxi Chuanghui Daye Metal Material Co., Ltd. operates advanced melting, forging, and rolling facilities dedicated to titanium material production. Each plate is vacuum-melted, hot-rolled, and precision-leveled to achieve uniform thickness and excellent flatness.

Our processing capacity supports large-format plates up to 2000 mm in width, providing reliable supply for industrial-scale fabrication projects.

​​​​​	​​​​​	​​​​​	​​​​​
​​​​​	​​​​​	​​​​​	​​​​​

Quality Assurance

Each plate undergoes rigorous inspection to ensure compliance with international standards:

• Spectrometric chemical analysis
• Tensile and yield strength testing
• Ultrasonic flaw detection
• Surface roughness and flatness inspection
• Dimensional tolerance verification

Mill Test Reports (MTRs) are provided with each order for complete traceability, ensuring quality confidence for bulk buyers.

Application Advantages​​​​​​​

• Gr2 titanium plates are widely used in sectors where corrosion resistance and long-term durability are essential, including:
• Chemical processing and storage equipment
• Heat exchangers and condensers
• Desalination and seawater systems
• Power generation and environmental engineering
• Aerospace and marine structures

R&D and Customization

Our engineering team focuses on optimizing plate performance for industrial, marine, and energy applications. We support customized thickness, tolerance, and surface finish to meet unique project specifications.

OEM and ODM services are available for large-scale production, including prototype trials, machining guidance, and material testing support.

Packaging & Logistics

Each Gr2 titanium plate is carefully packed using vacuum-sealed film, anti-rust paper, and export-grade wooden crates. Custom labeling with material grade, dimensions, and batch number ensures accurate inventory management.

We offer flexible global logistics solutions, supporting air, sea, and land transport for wholesale shipments.

​​

​​

​​

​​	​​	​​	​
​​	​​	​​	​​​​​​​​​

Global Cooperation & Certification

Shaanxi Chuanghui Daye has established long-term supply relationships with chemical, marine, and aerospace clients in Europe, America, and Asia. The factory operates under ISO 9001:2015 certification and ensures full export compliance.

We welcome wholesale distributors, industrial users, and engineering contractors to partner with us for reliable and consistent titanium plate supply.

​​​​​Why Choose Us :

1. You can get the perfect material according to your requirement at the least possible price.

2. We offer FOB, CFR, CIF, and door to door delivery prices. We suggest you to do deal for shipping which will be quite economical.

3. The materials we provide are completely verifiable, right from raw material test certificate to the final dimensional statement.(Reports will show on requirement)

4. You can get stock alternatives, mill deliveries with minimizing manufacturing time.

5. We are fully dedicated to our customers. If it will not possible to meet your requirements after examining all options, we will not mislead you by making false promises which will create good customer relations.

Sample order is supported!





​​​​​

​​​​​

​​​​​

​​​​​

​​​​​

​​​​​

1.First contact us to provide the grade, size ,quantity and standard or any special requirements.

2.we will reply you the quotation with delivery time in 3 hours.

3.reach an agreement then buyer arrange the prepayment.

4. when we get your payment we will arrange production asap and share you the production progress.

5.when production finished, will give buyer the actual weight of the products, then the buyer arrange balance payment.

6. Arrange shipment according to the most economical form we have agreed on

7.Meanwhile send buyer the material certificate.

8. Regular after-sales service to know the actual product usage.
