China Customized titanium 0.5 mm sheet Wholesale Suppliers Factory

Looking for high-quality titanium 0.5 mm sheet for your next project? Shaanxi Chuanghui Daye Metal Material Co., Ltd. delivers premium ultra-thin titanium sheets that combine exceptional strength with remarkable lightweight properties. Our precisely manufactured titanium sheets offer outstanding corrosion resistance and superior performance across diverse industrial applications. Whether you need materials for aerospace components, medical devices, or chemical processing equipment, our titanium products meet the highest industry standards.

Product Introduction

Our titanium sheets deliver unmatched performance in ultra-thin applications. These precision-engineered materials feature excellent formability while maintaining structural integrity. You can rely on our products for critical applications where weight reduction and corrosion resistance are essential.

Each sheet undergoes rigorous quality control to ensure consistent thickness and surface finish. Our advanced manufacturing processes guarantee precise dimensional tolerances that meet your exact specifications.

Key Features and Benefits

Superior Corrosion Resistance: Our titanium sheets resist harsh chemical environments, saltwater, and extreme temperatures. This makes them perfect for marine and chemical processing applications.

Lightweight Design: Titanium offers an excellent strength-to-weight ratio, reducing overall component weight without compromising performance.

Biocompatibility: Medical-grade titanium ensures safe use in surgical instruments and implantable devices.

Excellent Formability: The 0.5mm thickness allows for complex forming operations while maintaining material integrity.

Temperature Stability: Performs reliably across wide temperature ranges, from cryogenic to elevated temperatures.

Technical Specifications

Property	Value
Thickness	0.5MM
Width Range	Up to 2000MM
Length Range	1000-3000MM
Density	4.51g/cm³
Tensile Strength (Gr2)	345-483MPA
Yield Strength (Gr2)	275 min MPA
Elongation	20% min
Surface Finish	2B, BA, Polished
Certificate	ISO 9001:2015
Surface treatment	Cold-rolling
Standard	ASTM B 265
Production time	Normal size need 3-5 days and customized need 10-15 days
Payment terms	30%TT in advance, 70% balance before shipment

Physical constants and thermal properties

Density	4,51g/cm²
Melting point	1670°C
Beta transus temperature	920 ± 4°C
Thermal conductivity at 20°C	16 W/ m°C

Available Grades and Materials

Grade 2 (Commercially Pure): Offers excellent formability and corrosion resistance. Perfect for chemical processing and architectural applications.

Grade 5 (Ti-6Al-4V): Provides higher strength and enhanced mechanical properties. Ideal for aerospace and high-performance applications.

Both grades meet ASTM B265 standards and come with complete material certifications.

	N	C	H	Fe	O	Al	V	Pa	Mo	Ni	Ti
Gr 1	0.03	0.08	0.015	0.20	0.18	/	/	/	/	/	bal
Gr 2	0.03	0.08	0.015	0.30	0.25	/	/	/	/	/	bal
Gr 5	0.05	0.08	0.015	0.40	0.20	5.5~6.75	3.5~4.5	/	/	/	bal

Grade	Status	Tensile Strength		Yield Strength		Elongation	Area of Reducation
		Ksi	Mpa	Ksi	Mpa	%
		≥
GR1	Annealed	35	240	25	170	24	30
GR2		50	345	40	275	20	30
GR5		130	895	120	828	10	25

Manufacturing Process

Our titanium 0.5 mm sheet production follows strict quality protocols:

Cold Rolling: Achieves precise thickness control and superior surface finish.

Annealing: Optimizes mechanical properties and relieves internal stresses.

Surface Treatment: Ensures consistent finish and removes surface contaminants.

Quality Inspection: Every sheet undergoes dimensional and surface quality checks.

Raw material inspection

Titanium Melting

Titanium forging

Machining and forming

Final inspection

Packaging

Applications and Industries

Aerospace Industry: Aircraft skin panels, ductwork, and lightweight structural components.

Medical Sector: Surgical instruments, dental implants, and medical device housings.

Chemical Processing: Heat exchangers, reaction vessels, and corrosion-resistant equipment.

Marine Applications: Offshore platforms, submarine components, and seawater systems.

Electronics: Shielding components and precision electronic housings.

Be used in a wide range of industries.

Marine engineering

Medical implants

Medical Equipment

Chemical Processing

Aerospace and Defense

Energy and Environmental Engineering

Product Dimensions and Tolerances

Our precision manufacturing ensures tight dimensional control:

Thickness tolerance: ±0.02mm
Width tolerance: ±2.0mm
Length tolerance: ±3.0mm
Flatness: 2mm per meter maximum

Product Features in Detail

The ultra-thin profile of our sheets enables innovative design solutions. You can achieve complex geometries through forming operations while maintaining material properties. The smooth surface finish eliminates the need for additional processing in many applications.

Our titanium 0.5 mm sheet maintains consistent mechanical properties throughout the entire surface area. This reliability ensures predictable performance in critical applications.

Quality Assurance and Testing

Every product batch undergoes comprehensive testing:

Chemical composition analysis
Mechanical property verification
Dimensional inspection
Surface quality assessment
Ultrasonic testing when required

We maintain ISO quality management systems to ensure consistent product excellence.

iso certificate

certificate

OEM & Customization Services

We offer tailored solutions for your specific requirements:

Custom dimensions and tolerances
Special surface treatments
Precision cutting services
Small batch production capabilities

Our engineering team works closely with you to develop optimal material solutions.

Packaging and Shipping

Products are carefully packaged to prevent damage during transport:

Protective paper interleaving
Wooden crate packaging for larger orders
Moisture-resistant wrapping
Secure loading for international shipping

We coordinate with reliable logistics partners to ensure timely delivery worldwide.

Why Choose Us

With over 30 years of rare metal industry experience, we understand your material needs. Our location in China's "Titanium Capital" provides access to premium raw materials and advanced processing capabilities.

We serve customers in more than 50 countries, building lasting partnerships through reliable quality and service. Our commitment to continuous improvement ensures you receive the best titanium 0.5 mm sheet products available.

Certification

FAQs

Q: What is the minimum order quantity?

A: We accommodate both large production runs and small prototype quantities.

Q: Can you provide custom cutting services?

A: Yes, we offer precision cutting to your exact specifications.

Q: What certifications do you provide?

A: We supply complete material test certificates with every shipment.

Q: How do you ensure consistent quality?

A: Our comprehensive quality management system includes multiple inspection points throughout production.

Contact Us

Ready to discuss your titanium 0.5 mm sheet requirements? Our technical team is here to help you select the optimal material solution for your application.

Contact us today at info@chdymetal.com for detailed specifications, pricing, and delivery information. Let us be your trusted partner for premium titanium materials.
