Niobium Wire 20 Gauge (0.81 mm): High-Purity Nb >99.9% Wire for Jewelry and Electronics, Custom Lengths

Niobium wire 20 gauge is supplied by Shaanxi Chuanghui Daye Metal Material Co., Ltd. Jewelry makers buy this wire. Buyers in electronics take it as well. What they need is a fine refractory metal wire with very high purity. The diameter measures 0.81 mm. Nb content stays above 99.9%. Its surface comes polished. Lengths get cut to whatever you order. Hand-formed jewelry is one use. Electronic parts are another. Tensile strength is listed at 200–350 MPa. Density comes in at 8.57 g/cm³. The company sits in Baoji High-tech Development Zone. Specifications are covered in the sections below. Uses and handling are covered too. How to request a quote is explained there as well.

What Is Niobium Wire?

Niobium (Nb, atomic number 41) is one of the refractory metals. High heat is needed before it melts. This metal bends easily. Many corrosive media do not attack it. Where a fine metal filament is required, a wire drawn from it will fit. Chemical stability has to hold in that filament.

Specifications

The table lists the data supplied for this product.

Property	Value
Alloy	Nb >99.9%
Diameter	0.81 mm (20 gauge)
Maximum Length	as your customized
Tensile Strength	200–350 MPa
Density	8.57 g/cm³
Surface Finish	Cold rolling Bright
Melting Point	2,477°C
Electrical Conductivity	6.7×10⁶ S/m
Standard	ASTM B362
Certificate	ISO 9001:2015
Condition	Annealed
Delivery time	Stock size will be 1-5 days,normal production time is about 15 days
Payment terms	30%TT in advance,70% balance before shipment

Some details were never provided, so they do not appear here. Diameter tolerance and temper are missing. Grade designation is absent as well. The same holds for packaging and MOQ. Neither lead time nor certificates are listed. Before you order, ask us to confirm any of them.

Electron beam melting

Forging

Rolling

Machining and forming

Dimension inspection

Packaging

Key Features of This 0.81 mm Wire

High purity: Nb content comes in above 99.9%. Fine work needs a clean base metal, and this gives you one.
Defined size: Measured across the wire, it comes to 0.81 mm. That is 20 gauge.
Tensile strength: The specs put it at 200–350 MPa.
Density: The table gives 8.57 g/cm³. Pair that with the 0.81 mm diameter, and a single meter of wire comes to about 4.4 g. That figure is an estimate, not a measurement. Still, it helps you plan quantities.
Polished surface: The finish is smooth. Jewelry makers gain from this. Electronic parts do too.
Custom length: Your order sets the length. Every piece gets cut to it.

Applications

Jewelry: Fine niobium wire gets picked by designers for hand-shaped pieces and for wirework. Planning a design? Compare it to the 0.81 mm diameter on the list and to the polished surface of niobium wire 20 gauge.

Electronics: Electronic parts are one use on the list for this wire. It also acts as the electrode feed-through inside high-pressure sodium lamps. Thermal expansion stays close to alumina ceramic. Check that it suits your own design, though.

Grades, Purity and Alloy Options

This wire has a purity of Nb >99.9%. No grade designation appears in the data supplied. ASTM B392 and other standards are often used to set niobium grades. This page makes no claim that the wire meets any standard.

Higher-purity grades of niobium are available as well. Alloys get made too, and these include Nb-Ti, Nb-1Zr and C-103. Need another grade or alloy for your project? Send us the requirement. We will take a look.

Be used in a wide range of industries.

Electronic devices

Medical implants

Steel industry

Chemical Processing

Aerospace and Defense

Energy and Environmental Engineering

Welding, Handling and Storage

Treat these notes as general guidance for niobium wire.

Electron beam welding in vacuum works. Another option is TIG welding inside an inert gas chamber, using argon or helium.
Above about 200 °C, niobium reacts with oxygen and nitrogen. That reaction can cause embrittlement.
Store the wire in a cool, dry place.
Gloves go on first, before you touch it. Keep grease off the surface. Oil and fingerprints should stay away too.
Leftover organic matter can turn into carbon contamination later, when the part goes through heat treatment. That can harm the metal's properties.

About the Supplier of niobium wire 20 gauge

Shaanxi Chuanghui Daye Metal Material Co., Ltd. is a supplier of titanium, tantalum, niobium, tungsten, molybdenum, zirconium, nickel and other non-ferrous and rare metal alloy products. Metallurgy, electronics, medical and special steel fields all use these products.

The founder has more than 30 years of work in the rare metal industry, the company says. Products from the firm have reached buyers in over 50 countries. The United States is one of them. Germany is too. South Korea and Singapore are also on the list.

Before you place your order for niobium wire 20 gauge, settle a few details. Check the diameter you need. Length and purity need a check too. Then confirm how many you want. Decide how the surface should be finished. Test documents may matter to you. Ask if they can be supplied with your order.

Certification

Material	Main elements(%)	Impurities (Maximum %)
Material	Nb	Fe	Si	Ni	W	Mo	Ti	Ta	O	C	H	N
RO4200	Remainder	0.004	0.004	0.002	0.005	0.005	0.002	0.07	0.015	0.0040	0.0015	0.003
RO4210	Remainder	0.01	0.01	0.005	0.02	0.01	0.004	0.10	0.02	0.01	0.0015	0.01

Diameter	Tolerance	Roundness
0.2-0.5	±0.007	0.005
0.5-1.0	±0.01	0.01
1.0-1.5	±0.02	0.02
1.5-3.0	±0.03	0.03

iso certificate

certificate

FAQ About Niobium Wire

Q: What size and length can I order?

A: This wire is niobium, 20 gauge. Across, it measures 0.81 mm. Niobium content sits above 99.9%, and the surface comes polished. Any length you need can be ordered, and we cut it to size.

Q: Is there a set grade for this wire?

A: The data we have gives purity as Nb >99.9%. No grade designation is listed. If you need a set grade or alloy, tell us what you require.

Q: Can niobium wire be welded?

A: Yes. The atmosphere has to be controlled tightly. Electron beam welding in vacuum works. TIG welding in argon or helium also works.

Q: Does niobium wire hold up against every acid?

A: No. Many acids leave niobium alone. Hydrofluoric acid does attack it, though. Any solution with fluoride in it will do the same. Make sure it suits your own conditions before you commit.

Q: How should I store niobium wire?

A: Store it somewhere cool and dry. Grease should not get on it, and neither should oil. Wipe off fingerprints too. Put gloves on before you touch it.

Contact Us

Email us about niobium wire 20 gauge at info@chdymetal.com with your required length, quantity and intended use. Our team will reply with details for your order.
