6al4v titanium bar

Product Introduction

Looking for high-performance titanium bars that deliver exceptional strength and corrosion resistance? Our 6al4v titanium bar products represent the gold standard in titanium alloy solutions. As one of the most widely used titanium alloys worldwide, these Grade 5 bars combine 6% aluminum and 4% vanadium with pure titanium. This creates an alpha-beta alloy structure that offers superior mechanical properties. Whether you need materials for aerospace applications, medical devices, or industrial components, our titanium bars provide the reliability you demand.

Key Features and Benefits

Our titanium bars offer remarkable advantages that set them apart from conventional materials:

Superior Strength-to-Weight Ratio: These bars deliver strength comparable to steel while weighing 40% less, making them perfect for weight-critical applications.

Outstanding Corrosion Resistance: Excellent performance in marine environments, chemical processing, and other corrosive conditions ensures long-lasting durability.

Biocompatibility: Safe for medical implants and surgical instruments, meeting strict healthcare industry standards.

Temperature Stability: Maintains structural integrity at elevated temperatures up to 600°F (316°C).

Excellent Machinability: Easy to machine, weld, and form into complex shapes without compromising material properties.

Technical Specifications

Our bars conform to multiple international standards:

• ASTM B348 - Standard specification for titanium bars
• Density: 0.163 lb/in³ (4.43 g/cm³)
• Tensile Strength: 130-140 ksi minimum
• Yield Strength: 120-130 ksi minimum
• Elongation: 10% minimum

The Chemical Composition

Mechanical properties reference standard

Available Grades and Materials

We stock various forms of Grade 5 titanium:

• Standard 6AL-4V: For general aerospace and industrial applications
• 6AL-4V ELI (Extra Low Interstitial): Enhanced biocompatibility for medical use
• Annealed Condition: Maximum ductility and formability
• Solution Treated and Aged: Higher strength properties

Manufacturing Process

Our manufacturing process ensures consistent quality and superior performance:

Primary Melting: Starting with vacuum arc remelting (VAR) or electron beam melting for purity

Secondary Processing: Hot working and forging to achieve desired mechanical properties

Heat Treatment: Carefully controlled annealing or solution treatment and aging

Quality Control: Comprehensive testing throughout production

Final Inspection: Dimensional verification and material certification

​​​​​	​​​​​	​​​​​	​​​​​
​​​​​	​​​​​	​​​​​	​​​​​

​​​​​

Raw material inspection

​​​​​

Titanium Melting

​​​​​

Titanium forging

​​​​​

Machining and forming

​​​​​

Final inspection

​​​​​

Packaging

Applications and Industries

The versatility of 6al4v titanium bar makes it essential across numerous sectors:

Aerospace: Aircraft structural components, engine parts, fasteners, and landing gear

Medical: Surgical implants, orthopedic devices, dental implants, and surgical instruments

Marine: Offshore equipment, submarine components, and corrosion-resistant hardware

Automotive: High-performance racing components and exhaust systems

Chemical Processing: Reactor vessels, heat exchangers, and piping systems

Sports Equipment: Golf clubs, bicycle frames, and professional sporting goods

Be used in a wide range of industries.



​​​​​

Metallurgy and Special Steel

​​​​​

Electronics and Semiconductors

​​​​​

Medical Equipment

​​​​​

Chemical Processing

​​​​​

Aerospace and Defense

​​​​​

Energy and Environmental Engineering

Product Dimensions and Tolerances

We maintain strict dimensional tolerances to meet your specifications:

• Diameter Range: 0.125" to 12" (3.2mm to 304.8mm)
• Length: Up to 12 feet (3.66m) standard, longer lengths available
• Tolerance: ±0.005" on diameter, ±0.125" on length
• Surface Finish: Centerless ground, turned, or as-rolled options
• Straightness: 0.005" per foot maximum deviation

Quality Assurance and Testing

Every 6al4v titanium bar undergoes rigorous quality testing:

Chemical Analysis: Verification of alloy composition and purity levels

Mechanical Testing: Tensile, yield, and elongation properties confirmation

Ultrasonic Inspection: Internal flaw detection for critical applications

Surface Inspection: Visual and penetrant testing for surface defects

Dimensional Verification: Precise measurement of all specifications

Material Certification: Complete mill test certificates provided

OEM & Customization Services

We understand that every application has unique requirements:

• Custom lengths and diameters to your specifications
• Special heat treatments for enhanced properties
• Precision machining services available
• Surface treatments and coatings
• Just-in-time delivery programs
• Technical support throughout your project

Packaging and Shipping

Your materials arrive safely and ready for use:

Protective Packaging: Wooden crates or steel containers prevent damage during transit

Material Identification: Clear labeling with grade, dimensions, and lot numbers

Documentation: Complete certifications and test reports included

Global Shipping: Reliable delivery to over 50 countries worldwide

Expedited Options: Rush delivery available for urgent requirements

​​	​​	​​	​
​​	​​	​​	​​

Why Choose Us

Shaanxi Chuanghui Daye Metal Material Co., Ltd. brings over 30 years of rare metal expertise to every order. Located in China's "Titanium Capital," we offer unmatched access to premium materials and manufacturing capabilities. Our commitment to quality assurance and customer service has earned trust from clients across the United States, Germany, South Korea, Singapore, and beyond.

We provide competitive pricing, on-time delivery, and reliable partnership you can count on. Our experienced team offers technical support to help you select the right 6al4v titanium bar for your specific application.

​​​​​

​​​​​

​​​​​

​​​​​

​​​​​

​​​​​

FAQs

Q: What's the difference between Grade 5 and Grade 23 titanium?

A: Grade 23 (6AL-4V ELI) has lower interstitial content, making it more biocompatible for medical applications.

Q: Can you provide custom lengths?

A: Yes, we offer custom cutting and machining services to meet your exact specifications.

Q: What certifications do you provide?

A: We supply complete mill test certificates with chemical and mechanical property verification.

Q: Do you offer technical support?

A: Absolutely. Our experienced team provides guidance on material selection and application requirements.
