titanium foil roll

Product Introduction

Looking for ultra-thin titanium solutions that deliver exceptional strength and corrosion resistance? Our titanium foil roll represents the pinnacle of precision metal processing technology. This high-performance material combines the inherent advantages of titanium with the convenience of continuous roll format, making it perfect for automated manufacturing processes. Whether you're developing aerospace components, medical devices, or energy systems, our titanium foil roll provides the reliability and consistency your applications demand.

What Makes Our Titanium Foil Roll Superior?

Our titanium foil roll stands out in the market due to its exceptional manufacturing quality and versatility. Each roll undergoes precise cold-rolling processes followed by vacuum annealing to achieve optimal mechanical properties.

Key Material Properties

The unique characteristics of our product make it ideal for demanding applications:

• Lightweight Excellence: At just 4.51 g/cm³, it's 45% lighter than steel
• Superior Strength: High strength-to-weight ratio outperforms conventional materials
• Corrosion Immunity: Natural TiO2 oxide layer provides outstanding protection
• Temperature Stability: Maintains integrity from cryogenic to high-temperature environments
• Biocompatibility: Safe for medical and food-grade applications
• Non-magnetic Properties: Perfect for sensitive electronic applications

Technical Specifications

Parameter	Specification
Grades Available	Gr1, Gr2, Gr5, Gr7, Gr9, Gr12
Thickness Range	0.01mm - 0.5mm
Width	Up to 350mm (customizable)
Length	Up to 3000mm (customizable)
Standards	ASTM B265
Surface Finish	Bright/Polished/Machined
State	Annealed
Tolerance	±3% to ±5%
Surface Roughness	Ra < 0.2μm
Certificate	ISO9001:2015
Form	Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip,
Delivery time	1.Usually,within10-15 days after receiving deposit 2.According to the order quantity
Payment terms	30%TT prepayment in advance, 70% balance before shipment

Grade Selection Guide

Different grades offer specific advantages for various applications:

Grade 1: Pure titanium with excellent ductility and formability. Perfect for deep drawing applications requiring maximum workability.

Grade 2: The most versatile pure titanium grade. Offers the best balance of strength, weldability, and corrosion resistance.

Grade 5 (Ti-6Al-4V): High-strength titanium alloy with exceptional heat resistance. Ideal for aerospace and high-performance applications.

Grade 7: Enhanced corrosion resistance in both reducing and oxidizing environments. Excellent for chemical processing equipment.

Grade 9: Combines high strength with superior corrosion resistance. Perfect for demanding industrial applications.

Grade 12: Better heat resistance than pure titanium, suitable for elevated temperature applications.

Chemical composition:

	N	C	H	Fe	O	Al	V	Pa	Mo	Ni	Ti
Gr 1	0.03	0.08	0.015	0.20	0.18	/	/	/	/	/	bal
Gr 2	0.03	0.08	0.015	0.30	0.25	/	/	/	/	/	bal
Gr 3	0.05	0.08	0.015	0.30	0.35	/	/	/	/	/	bal
Gr 4	0.05	0.08	0.015	0.50	0.40	/	/	/	/	/
Gr 5	0.05	0.08	0.015	0.40	0.20	5.5~6.75	3.5~4.5	/	/	/	bal
Gr 7	0.03	0.08	0.015	0.30	0.25	/	/	0.12~0.25	/	/	bal
Gr 9	0.03	0.08	0.015	0.25	0.15	2.5~3.5	2.0~3.0	/	/	/	bal
Gr12	0.03	0.08	0.015	0.30	0.25	/	/	/	0.2~0.4	0.6~0.9

Mechanical property:

Material	Condition	Thickness mm	Mechanical Property
			Tensile strength Rm/Mpa	Yield strength Rp0.2/Mpa	Elongation A%
Gr1	M	<25	Min 240	Min 170 Max 310	Min 24
Gr2	M	<25	Min 345	Min 275 Max 450	Min 20
Gr3	M	<25	Min 450	Min 380 Max 550	Min 18
Gr4	M	<25	Min 550	Min 438 Max 660	Min 15



Manufacturing Excellence

Advanced Production Process

Our manufacturing process ensures consistent quality and performance:

Cold Rolling: We utilize advanced multi-high rolling mills to achieve precise thickness control and superior surface finish.

Heat Treatment: Our vacuum annealing process optimizes mechanical properties while maintaining surface quality. This controlled atmosphere prevents contamination and ensures consistent metallurgical structure.

Quality Control: Every batch undergoes rigorous testing for dimensional accuracy, mechanical properties, and surface quality.

​​​​​	​​​​​	​​​​​	​​​​​
​​​​​	​​​​​	​​​​​	​​​​​

Diverse Applications Across Industries

Aerospace Industry

Your aircraft components benefit from our material's lightweight properties and high-temperature stability. It's extensively used in engine parts, structural components, and heat shields where weight reduction directly improves fuel efficiency.

Energy Sector

In fuel cells and electrolyzers, our product serves as substrate material for bipolar plates. Its corrosion resistance ensures long-term performance in aggressive electrochemical environments.

Medical Devices

The biocompatible nature makes it ideal for surgical instruments, implants, and medical device components. Its non-toxic properties ensure patient safety.

Electronics Manufacturing

You'll find our material perfect for capacitors, batteries, and precision electronic components where conductivity and thermal stability are crucial.

Automotive Industry

Modern vehicles benefit from our lightweight solutions in exhaust systems and structural components, contributing to improved fuel economy and performance.

Chemical Processing

Heat exchangers, reactors, and storage tanks utilize our material's exceptional corrosion resistance in harsh chemical environments.

Why Choose Shaanxi Chuanghui Daye Metal Material?

With over 30 years of experience in rare metal processing, we understand your specific requirements. Located in China's "Titanium Capital" of Baoji, we have access to premium raw materials and advanced manufacturing facilities.

Our commitment to quality ensures that every titanium foil roll meets international standards. We serve customers across more than 50 countries, providing competitive pricing, on-time delivery, and exceptional customer service.

Our Promise to You

• Quality Assurance: Every product meets stringent quality standards
• Custom Solutions: We tailor specifications to meet your exact requirements
• Technical Support: Our experienced team provides comprehensive technical assistance
• Global Reach: Reliable delivery to customers worldwide
• Competitive Pricing: Cost-effective solutions without compromising quality

​​​​​

​​​​​

​​​​​

​​​​​

​​​​​

​​​​​

Get Started Today

Ready to experience the superior performance of our titanium foil roll? Our team is here to help you select the right grade and specifications for your application. Whether you need standard dimensions or custom configurations, we have the expertise to deliver exactly what you need.

Contact us at info@chdymetal.com to discuss your requirements. Let us show you how our premium titanium solutions can enhance your manufacturing processes and product performance.

Trust in our expertise, rely on our quality, and experience the difference that professional titanium processing makes.
