titanium anode mesh

Product Introduction

When you need a reliable, long-lasting solution for electrochemical processes, titanium anode mesh delivers unmatched performance. This advanced Dimensionally Stable Anode (DSA) combines an expanded titanium substrate with specialized Mixed Metal Oxide coatings, offering superior durability and efficiency. Unlike traditional graphite or lead anodes that suffer from dissolution and contamination issues, our titanium anode mesh maintains consistent performance while eliminating electrolyte contamination. You'll benefit from reduced energy consumption and improved operational reliability.

What Makes Our Titanium Anode Mesh Superior?

Our titanium mesh anodes are engineered from high-purity titanium (Grade 1 or Grade 2) following ASTM B265 standards. The expanded metal geometry creates a continuous electrical pathway without contact resistance issues common in woven wire structures.

The secret lies in the catalytic coating. We apply specialized formulations including:

• Iridium-Tantalum (Ir-Ta) for oxygen evolution environments
• Ruthenium-Iridium (Ru-Ir) for chlorine evolution applications
• Platinum plating for high-conductivity requirements

This combination delivers current efficiency rates of 80-90% while maintaining dimensional stability throughout the service life.

Key Applications Where You'll See Maximum Benefits

Impressed Current Cathodic Protection (ICCP)

Your infrastructure projects demand reliable corrosion protection. Our mesh integrates seamlessly into concrete overlays for bridges, parking decks, and tunnels. The ribbon-like structure distributes protection current uniformly to rebar networks, stopping corrosion in high-chloride environments without adding structural weight.

Water Treatment Systems

For chlor-alkali processes and hypochlorite generation, you need anodes that withstand harsh oxidative environments. Our titanium anode mesh excels in electrochlorinators for ballast water treatment and pool sanitation systems, efficiently converting brine to sodium hypochlorite.

Metal Recovery and Electroplating

When processing precious metals, purity is paramount. The mesh design maximizes active surface area, enabling higher current densities and faster deposition rates. Your gold, silver, and copper recovery operations remain contamination-free since the anode doesn't dissolve into the electrolyte.



Technical Specifications

Parameter	Specification
Grade	Gr1, Gr2
Size	Customized to requirements
Configuration	Straight or coiled
Standard Mesh Openings	2×3mm, 3×4mm, 3×6mm, 4×8mm, 5×10mm, 6×12mm, 6.5×12.5mm, 7×18mm
Coating Options	Ir-Ta, Ru-Ir, Platinum
Current Efficiency	80-90%
Service Life	5-20+ years (coating dependent)
Standards Compliance	ASTM B265
Certificate	ISO 9001:2015
Size	As your drawing
Parameter	1. Current density≤2000A/M2 2. Temperature<60°C 3. PH 0.1~14  4. Max content of Fluoride ion is 200PPM
Advantages	1. Effective and environmental   2. High current efficiency  3. High anti-corrosion property  4. Long working life 5. Keep the operating voltage stably 6. Small size & light weight

Why Choose Shaanxi Chuanghui Daye Metal Material?

Located in China's "Titanium Capital," we bring over 30 years of rare metal industry expertise to every project. Our founder's deep technical knowledge ensures you receive products that meet your exact specifications.

We've successfully delivered solutions to customers across 50+ countries, including the United States, Germany, South Korea, and Singapore. Our focus on quality assurance and customer-first service means you get:

• Competitive pricing without compromising quality
• On-time delivery that keeps your projects on schedule
• Customized solutions tailored to your specific applications
• Reliable technical support throughout the product lifecycle

​​​​​

​​​​​

​​​​​

​​​​​

​​​​​

​​​​​

Extending Your Investment Value

One significant advantage of titanium anode mesh is its renewability. When the catalytic coating reaches end-of-life, the titanium substrate typically remains intact. We can sandblast the old coating, pickle the substrate, and apply fresh MMO layers, restoring full functionality at a fraction of new unit costs.

This recoating capability makes your initial investment even more valuable, providing decades of reliable service with periodic maintenance.

Getting Started

Your electrochemical challenges require proven solutions. Whether you're protecting concrete infrastructure, treating water, or recovering precious metals, our titanium mesh anodes deliver the performance and longevity you need.

Contact us at info@chdymetal.com to discuss your specific requirements. Our technical team will work with you to determine the optimal mesh configuration, coating type, and specifications for your application. We're committed to providing products that exceed your expectations while delivering exceptional value.

Ready to experience the difference that quality titanium anode mesh makes? Let's start the conversation today.
