gr 5 titanium plate



Looking for high-performance titanium solutions? Our gr 5 titanium plate delivers exceptional strength and corrosion resistance for demanding applications. Made from Ti-6Al-4V alloy, this premium grade titanium plate combines 90% pure titanium with 6% aluminum and 4% vanadium. You get superior mechanical properties with a lightweight design that's perfect for aerospace, medical, and industrial uses. With over 30 years of experience in rare metal manufacturing, we provide reliable quality that meets international standards.

Product Introduction



Grade 5 titanium represents the most widely used titanium alloy in modern engineering. Our plates feature the proven Ti-6Al-4V composition that delivers outstanding performance across multiple industries. You'll find these plates offer excellent strength-to-weight ratios while maintaining superior corrosion resistance in challenging environments.

Key Features and Benefits

• High Strength: Tensile strength ranges from 895-960 MPa
• Lightweight Design: Density of only 4.43 g/cm³
• Excellent Corrosion Resistance: Superior performance in harsh environments
• High Fatigue Resistance: Perfect for cyclic loading applications
• Biocompatibility: Safe for medical and food industry use
• Wide Temperature Range: Maintains properties from -253°C to 400°C
• Easy Machinability: Excellent workability for complex shapes

Technical Specifications

Property	Value
Alloy Composition	Ti-6Al-4V (90% Ti, 6% Al, 4% V)
Tensile Strength	895-960 MPa
Yield Strength	828-896 MPa
Density	4.43 g/cm³
Elongation	≥10%
Thickness Range	1-50mm
Operating Temperature	-253°C to 400°C
Certificate	ISO 9001:2015
Process	cold rolling / hot rolling
Surface	Bright surface
Condition	Annealed
Payment terms	30% TT in advance, 70% balance before shipment

Available Grades and Materials

We specialize in gr 5 titanium plate production with various surface finishes:

• Hot rolled condition
• Cold rolled condition
• Annealed condition
• Pickled surface finish
• Machined surface finish

Manufacturing Process

Our advanced manufacturing process ensures consistent quality:

1. Raw Material Selection: Premium titanium sponge and alloy elements
2. Vacuum Arc Remelting: Creates homogeneous alloy structure
3. Hot Rolling: Achieves desired thickness and mechanical properties
4. Heat Treatment: Optimizes microstructure for specific applications
5. Quality Testing: Comprehensive inspection at every stage
6. Surface Treatment: Professional finishing for your requirements

​​​​​	​​​​​	​​​​​	​​​​​
​​​​​	​​​​​	​​​​​	​​​​​

Applications and Industries

Aerospace Industry:

• Aircraft structural components
• Engine parts and turbine blades
• Spacecraft components

Medical Field:

• Surgical instruments
• Implants and prosthetics
• Medical device components

Industrial Applications:

• Chemical processing equipment
• Offshore oil and gas platforms
• Marine applications

Product Dimensions and Tolerances

• Thickness: 1mm to 50mm (±0.1mm tolerance)
• Width: Up to 2000mm
• Length: Up to 6000mm
• Custom sizes available upon request

Product Features in Detail

Our gr 5 titanium plate stands out for its exceptional combination of properties. The aluminum content enhances strength while vanadium improves workability. You benefit from a material that's 40% lighter than steel yet stronger than most aluminum alloys. The naturally formed oxide layer provides outstanding corrosion protection without additional coatings.

Quality Assurance and Testing

Every plate undergoes rigorous testing:

• Chemical composition analysis
• Mechanical property testing
• Ultrasonic inspection
• Surface quality examination
• Dimensional verification
• Certificate of compliance included

OEM & Customization Services

We offer comprehensive customization options:

• Custom dimensions and thicknesses
• Specific mechanical properties
• Special surface treatments
• Machined components from plates
• Technical support throughout your project

Packaging and Shipping

Your orders receive professional packaging:

• Wooden crates for large plates
• Protective film wrapping
• Foam padding between pieces
• Moisture protection
• Clear labeling and documentation
• Worldwide shipping available

​​	​​	​​	​
​​	​​	​​	​​

Why Choose Us

Three Decades of Experience: Our founder brings over 30 years of rare metal industry expertise to every project.

Global Reach: We successfully serve customers in over 50 countries including the United States, Germany, South Korea, and Singapore.

Quality Focus: Located in China's "Titanium Capital" of Baoji, we maintain strict quality standards throughout production.

Customer-Centric Approach: We prioritize your needs with competitive pricing, on-time delivery, and responsive service.

Comprehensive Solutions: Beyond plates, we offer complete titanium alloy product lines for your diverse requirements.

​​​​​

​​​​​

​​​​​

​​​​​

​​​​​

​​​​​

FAQs

Q: What makes Grade 5 titanium different from pure titanium?

A: Grade 5 offers significantly higher strength and better fatigue resistance compared to pure titanium grades.

Q: Can you provide small quantities for prototyping?

A: Yes, we accommodate both small prototype orders and large production runs.

Q: What certifications do your products meet?

A: Our products comply with ASTM, AMS, and other international standards.

Q: How do you ensure consistent quality?

A: We implement comprehensive testing at every production stage with full traceability.

Contact Us

Ready to discuss your gr 5 titanium plate requirements? Our experienced team is here to help you find the perfect solution for your application.

Email: info@chdymetal.com

Contact us today for technical specifications, pricing information, or custom solutions. We're committed to providing you with reliable, high-quality titanium products that exceed your expectations.
