China Customized titanium grade 2 sheets and plates Wholesale Suppliers Factory

Product Introduction

When you need reliable metal materials for demanding applications, titanium grade 2 sheets and plates stand out as the perfect choice. At Shaanxi Chuanghui Daye Metal Material Co., Ltd., we specialize in manufacturing premium-quality titanium products that meet the highest industry standards. Our titanium grade 2 sheets and plates offer exceptional performance across diverse industries, from aerospace to medical applications. With over 30 years of experience in the rare metal industry, we understand your specific requirements and deliver solutions that exceed expectations.

Key Features and Benefits

Our grade 2 titanium products deliver outstanding value through their unique combination of properties. You'll appreciate their excellent corrosion resistance, which makes them ideal for harsh environments. The lightweight nature of these materials helps reduce overall project weight without compromising strength.

The superior biocompatibility makes them perfect for medical applications. Their non-magnetic properties ensure compatibility with sensitive equipment. You can count on consistent quality and reliable performance in critical applications.

Technical Specification

Property	Value
Thickness Range	0.5-50mm
Width Range	500-2000mm
Length Range	1000-6000mm
Titanium Content	99.2% min
Density	4.51 g/cm³
Melting Point	1660°C
Tensile Strength	345-483 MPa
Yield Strength	275-413 MPa
Elongation	20% min
Type	plate, sheet, foil, strip
Surface	Bright, Polished, Pickling, Sandblasting
Processing method	cold rolling / hot rolling
Package Terms	Moisture-proof cloth, foam cotton inside, wooden case outside.
Payment terms	30% TT prepayment, 70% balance payment before shipment

Available Grades and Materials

We primarily focus on Grade 2 titanium, which is commercially pure titanium. This grade contains maximum 0.25% iron, 0.03% carbon, 0.08% oxygen, and 0.015% nitrogen. The composition ensures optimal balance between strength and formability.

Grade 2 represents the most versatile titanium grade available. It offers excellent weldability and can be easily formed using standard metalworking techniques. The material meets ASTM B265 and ASME SB265 specifications.

Chemical composition:

Grade	Ti	Chemical composition (%)
		Impurity(%) Max					Residual elements
		Fe	C	N	H	O	Single	Total
Gr2	Bal	0.30	0.08	0.03	0.015	0.25	0.10	0.40

Mechanical property:

Material

Condition

Thickness

Mechanical Property

Tensile strength

Rm/Mpa

Yield strength

Rp0.2/Mpa

Elongation

Gr2

<25

Min 345

Min 275 Max 450

Min 20

Manufacturing Process

Our manufacturing process begins with high-quality titanium sponge. We use advanced melting techniques to ensure chemical homogeneity. Hot rolling follows to achieve desired thickness ranges.

Cold rolling provides precise dimensional control and surface finish. Annealing treatments optimize mechanical properties. Quality control checks verify compliance with specifications throughout production.

Raw material inspection

Titanium Melting

Titanium forging

Machining and forming

Final inspection

Packaging

Applications and Industries

Chemical Processing: Titanium grade 2 sheets and plates excel in chemical environments where corrosion resistance is critical. They withstand exposure to acids, alkalis, and salt solutions.

Marine Industry: Seawater applications benefit from titanium's exceptional resistance to chloride corrosion. Offshore platforms and marine equipment rely on these materials.

Medical Sector: Surgical instruments and implants utilize titanium's biocompatibility. The material integrates well with human tissue and shows no adverse reactions.

Aerospace: Aircraft components require lightweight materials with high strength. Titanium meets these demanding requirements while maintaining structural integrity.

Be used in a wide range of industries.

Marine engineering

Medical implants

Medical Equipment

Chemical Processing

Aerospace and Defense

Energy and Environmental Engineering

Product Dimensions and Tolerances

Our standard thickness tolerance is ±0.05mm for materials under 5mm thick. Thicker materials maintain ±1% tolerance. Width tolerances are typically ±3mm for standard sizes.

Length tolerances follow industry standards at ±5mm. Special tolerances are available upon request. Custom dimensions can be manufactured to meet your specific project requirements.

Product Features in Detail

The excellent formability allows complex shapes without cracking. Superior weldability enables joining using standard techniques. Low thermal expansion minimizes dimensional changes during temperature variations.

High fatigue resistance ensures long service life under cyclic loading. Chemical inertness prevents contamination in sensitive applications. Easy machining characteristics reduce processing costs.

Quality Assurance and Testing

Every batch undergoes comprehensive chemical analysis to verify composition. Mechanical testing confirms tensile strength, yield strength, and elongation values. Ultrasonic testing detects any internal defects.

Surface quality inspection ensures smooth finishes. Dimensional verification confirms adherence to specifications. Certificate of compliance accompanies each shipment.

OEM & Customization Services

We understand that standard sizes don't always meet your needs. Our customization services include precision cutting to your exact dimensions. Special surface treatments are available when required.

Custom packaging options protect materials during shipping. Technical support helps optimize material selection for your application. Quick turnaround times keep your projects on schedule.

Packaging and Shipping

Materials are carefully packaged using protective wrapping to prevent surface damage. Wooden crates provide secure transportation for larger shipments. International shipping arrangements ensure global delivery.

Documentation includes material certificates and shipping manifests. Tracking information keeps you informed of delivery status. Insurance coverage protects your investment during transit.

Why Choose Us

Located in China's "Titanium Capital," we have access to the best raw materials and manufacturing expertise. Our founder's 30+ years experience ensures deep industry knowledge. We serve customers in over 50 countries worldwide.

Competitive pricing doesn't compromise quality. On-time delivery keeps your projects moving forward. Customer-focused service addresses your specific needs promptly and professionally.

Certification

FAQs

Q: What makes Grade 2 titanium different from other grades?

A: Grade 2 offers the best balance of strength, ductility, and corrosion resistance among commercially pure titanium grades.

Q: Can you provide custom dimensions?

A: Yes, we manufacture custom sizes to meet your specific requirements.

Q: What industries commonly use these products?

A: Chemical processing, marine, aerospace, and medical industries are primary users.

Q: How do you ensure quality?

A: Comprehensive testing including chemical analysis, mechanical testing, and dimensional verification.

Contact Us

Ready to discuss your titanium grade 2 sheets and plates requirements? Our experienced team is here to help you find the perfect solution for your project.

We look forward to becoming your trusted partner for high-quality titanium materials.
