China Customized tantalum r05400 sheet & plate Wholesale Suppliers Factory

Production introduction

When you need reliable, corrosion-resistant metal solutions for demanding applications, our tantalum r05400 sheet & plate delivers exceptional performance. Made through advanced powder-metallurgy consolidation, this unalloyed tantalum material offers superior workability and mechanical properties. At Shaanxi Chuanghui Daye Metal Material Co., Ltd., we specialize in manufacturing high-quality tantalum products that meet the strictest industry standards. Our R05400 grade tantalum sheets and plates provide excellent surface quality and fine-grained structure for your critical applications.

Key Features and Benefits

Our R05400 tantalum sheets and plates offer remarkable advantages for your projects:

Superior Corrosion Resistance: Withstands harsh chemical environments
Excellent Workability: Fine-grained structure makes forming and machining easier
High Temperature Stability: Maintains properties under extreme heat
Biocompatibility: Safe for medical applications and implants
Chemical Inertness: Non-reactive with most acids and chemicals
Consistent Quality: Uniform composition throughout the material

Technical Specifications

Property	Specification
Alloy Grade	Ta R05400
Thickness Range	0.5–20 mm
Width	Up to 1000 mm
Length	Up to 3000 mm
Density	16.65 g/cm³
Tensile Strength	200–300 MPa
Purity	99.95%
Processing Method	Powder-metallurgy consolidation
Standard	ASTM B708
Type	sheet, plate, foil, strip
Certificate	ISO 9001:2015
Condition	Annealed
Delivery time	Normal 7-15 days
Payment term	30%TT in advance, 70% balance before payment

Available Grades and Materials

We offer various tantalum grades to meet your specific requirements:

R05200: Unalloyed tantalum, electron-beam furnace or vacuum-arc melt
R05400: Unalloyed tantalum, powder-metallurgy consolidation
R05252: Tantalum alloy with 2.5% tungsten
R05255: Tantalum alloy with 10% tungsten

Chemical composition

Content, Max, Weight %
Element	R05200 Uanlloyed Tantalum	R05255 90% Tantalum 10% Tungsten	R05252 97.5% Tantalum 2.5% Tungsten	R05240 60% Tantalum 40% Niobium
C	0.010	0.010	0.010	0.010
O	0.015	0.015	0.015	0.020
N	0.010	0.010	0.010	0.010
H	0.0015	0.0015	0.0015	0.0015
Fe	0.010	0.010	0.010	0.010
Mo	0.020	0.020	0.020	0.020
Nb	0.100	0.100	0.50	35.0~42.0
Ni	0.010	0.010	0.010	0.010
Si	0.005	0.005	0.005	0.005
Ti	0.010	0.010	0.010	0.010
W	0.05	9.1~11.0	2.0~3.5	0.050
Ta	Remainder	Remainder	Remainder	Remainder

Manufacturing Process

Our manufacturing process ensures consistent quality and performance. We use advanced powder-metallurgy consolidation techniques that create a fine-grained structure. This process gives our tantalum r05400 sheet & plate superior workability compared to melted alternatives. The powder-metallurgy method allows for better control over material properties and results in excellent surface finish.

Electron beam melting

Forging

Rolling

Machining and forming

Dimension inspection

Packaging

Applications and Industries

Your tantalum sheets and plates find applications across multiple industries:

Chemical Processing: Reactor vessels, heat exchangers, and piping systems
Electronics: Capacitor components and semiconductor manufacturing
Medical Devices: Surgical implants and prosthetics
Aerospace: High-temperature components and engine parts
Nuclear Technology: Reactor components and containment systems
Laboratory Equipment: Corrosion-resistant apparatus and containers

Be used in a wide range of industries.

Electronic devices

Medical implants

Steel industry

Chemical Processing

Aerospace and Defense

Energy and Environmental Engineering

Product Dimensions and Tolerances

We maintain strict dimensional control to ensure your parts meet specifications:

Thickness tolerance: ±0.05mm for sheets under 5mm
Width tolerance: ±2mm for standard widths
Length tolerance: ±5mm for standard lengths
Surface finish: Ra 0.8μm or better
Flatness: Within 2mm per meter

Product Features in Detail

The fine-grained structure of our R05400 grade material provides several advantages. You'll find it easier to machine and form compared to other tantalum grades. The powder-metallurgy process creates uniform properties throughout the material thickness. This consistency ensures predictable performance in your applications.

Our tantalum r05400 sheet & plate exhibits excellent chemical resistance. It withstands attack from most acids, including hydrofluoric acid at room temperature. The material maintains its properties even under extreme conditions.

iso certificate

Quality Assurance and Testing

Every batch undergoes comprehensive testing to ensure quality:

Chemical composition analysis
Mechanical property testing
Surface quality inspection
Dimensional verification
Ultrasonic testing for internal defects

OEM & Customization Services

We understand that every application has unique requirements. Our team works closely with you to provide customized solutions. Whether you need specific dimensions, surface treatments, or special packaging, we can accommodate your needs. Our experienced engineers provide technical support throughout your project.

Packaging and Shipping

Your tantalum products are carefully packaged to prevent damage during transport. We use protective materials and secure packaging methods. Our logistics team coordinates with reliable shipping partners to ensure timely delivery to your location worldwide.

Why Choose Us

With over 30 years of experience in rare metals, we bring unmatched expertise to your projects. Located in China's "Titanium Capital," we have access to premium raw materials and advanced manufacturing facilities. Our products serve customers in more than 50 countries, demonstrating our commitment to quality and reliability.

We focus on customer satisfaction through competitive pricing, on-time delivery, and responsive service. Our quality management systems ensure consistent product performance that meets international standards.

Certification

FAQs

Q: What's the difference between R05200 and R05400 tantalum?

A: R05400 uses powder-metallurgy consolidation, resulting in finer grain structure and better workability compared to melted R05200.

Q: Can you provide material certificates?

A: Yes, we provide complete material certificates with chemical composition and mechanical properties for every shipment.

Q: What's the minimum order quantity?

A: We accommodate both small prototype quantities and large production orders based on your requirements.

Q: How long is the typical lead time?

A: Standard products typically ship within 1-2 weeks, while custom specifications may require 2-3weeks.
