pure tantalum wire

1. Alloy: Ta >99.9%
2. Diameter: 0.15–3mm
3. Tensile strength: 200–300 MPa
4. Density: 16.65 g/cm³
5. Corrosion resistant
6. Applications: Electronics, chemical industry
7. Elongation: 10–20%
Product Description

Pure Tantalum Wire for Capacitors, Medical Devices and Vacuum Furnaces: High-Purity Grades R05200 and R05400

Shaanxi Chuanghui Daye Metal Material Co., Ltd. (CHDY) runs its plant in Baoji High-tech Development Zone. From that site comes pure tantalum wire, produced in ASTM B365 grades R05200 and R05400. Capacitors use it. So do parts for medical devices, vacuum furnaces, and chemical processing equipment. Purity runs from 99.95% (3N5) up to 99.99% (4N). Some diameters go as low as 0.05 mm. You can order coils, spools or straight lengths. Grade and diameter are matched to what you need. Temper and surface finish are matched as well. Order quantity is your call. At CHDY, the founder has spent over 30 years in rare metals. Orders have shipped to more than 50 countries and regions.

Overview and Material Grades

Tantalum is a refractory metal. Its atomic number is 73. CHDY offers the wire in two ASTM B365 grades. R05200 is unalloyed tantalum made by electron beam melting. R05400 is unalloyed tantalum made by powder metallurgy. For high-purity wire drawing, R05200 is usually the preferred choice.

Buyers pick this product for three reasons. A stable anodic oxide layer forms on it, which is what capacitors need. Many acids do not touch it, hot hydrochloric and sulfuric acid included. It is biocompatible as well, so implants use it. Suitability for any medical device still has to be validated by the device manufacturer.

Key Properties

Cold workability. Tantalum is easy to shape when cold. It can be pulled into very thin wire, as small as 0.05 mm across. Annealed wire works well for bending and later forming steps. Wire that has not been annealed is harder. The temper you pick should match how you make the part.

Corrosion resistance. The wire grows an oxide layer, and plenty of harsh chemicals cannot get through it. Under 150 °C, most of them leave the metal alone. Exceptions exist. Hydrofluoric acid can attack it. So can some media that carry fluoride. Test those cases with care.

High-temperature behavior. Tantalum melts at about 3,000 °C. Air causes trouble, though. Once the metal goes past 300 °C, it starts to oxidize at a rate you can see. Nitrogen gets in as well. That turns it brittle. For work at high heat, use a vacuum or an inert gas.

How it handles heat and current. At 20 °C the electrical resistivity reads 13.5 µΩ·cm. Thermal expansion sits at 6.3 µm/m·K.

Specifications

Property Value
Alloy Composition Ta >99.9%
Diameter Range 0.15–3mm
Tensile Strength 200–300 MPa
Density 16.65 g/cm³
Elongation 10–20%
Melting Point 2996°C
Operating Temperature Up to 2000°C
Standard ASTM B365
Service Customized OEM, OEM/ODM/Customized, ODM Available
Packing Wooden box
Material

Pure tantalum: R05200, R05400;

TantalumTungsten Rod / Bar R05252 (Ta-2.5W), R05255 (Ta-10W).

Delivery time Stock size will be 1-5 days,normal production time is about 15 days
Payment terms 30%TT in advance,70% balance before shipment

Parameters not listed in this table are not stated on this page. Please confirm them with our team before ordering.

Certificationimg-15-15​​​​

Applications

Electrolytic capacitors. In these parts the wire becomes the anode lead. A controlled Ta₂O₅ film grows on the tantalum. That layer holds a high dielectric constant. Which explains why capacitor anodes so often use tantalum.

Medical implants and X-ray work. Metal still shows up on an X-ray. Tantalum is bio-inert and radiopaque, so the part stays visible. Radiographic markers rely on it. Sutures and vascular clips do too. Need that spec on your job? Put ASTM F560 on the inquiry.

Vacuum furnaces and coating equipment. Heating coils in these systems are made from pure tantalum wire. The same wire shows up in evaporation sources. It works because the melting point is so high. Gases get picked up by the metal at high heat too. Keep that in mind when you check the atmosphere in your process and how clean it needs to be.

Chemical processing and metal fabrication. Some parts in corrosive service can use this wire as well. Custom components are the other case.

Quality Control

Purity comes first when tantalum wire gets checked. Surface condition counts too. So does the way the wire acts under mechanical load. Four areas get covered in total.

  • Chemical analysis. GDMS (Glow Discharge Mass Spectrometry) picks up oxygen and carbon. Nitrogen and hydrogen turn up as well. Ductility drops once interstitial levels climb.
  • Surface inspection. Eddy current testing catches die marks. Microscope checks catch them too. Slivers and cracks turn up the same way. On capacitor leads, a smooth surface helps keep leakage current down.
  • Mechanical testing. Tensile strength gets verified against ASTM B365. Yield strength and elongation are measured the same way. Results show whether the wire is annealed or hard.
  • Dimensional control. Laser micrometers monitor diameter, often within ±1%, for automated assembly lines.

Please ask our team which test documents are available for your order.

Raw material inspection​​​​​
Electron beam melting
titanium Melting​​​​​
Forging
Titanium forging​​​​​
Rolling
Machining and forming​​​​​
Machining and forming
Final inspection​​​​​
Dimension inspection
packaging​​​​​
Packaging

Processing and Welding Guidance for pure tantalum wire

The wire gets cut, bent and formed, then built into industrial parts. Choose the method to match wire diameter and temper. Fine hard-drawn wire behaves nothing like annealed wire.

TIG welding works for tantalum. Electron beam welding works too. Keep the surfaces clean. To stop embrittlement, shield the weld with argon or helium.

Be used in a wide range of industries.



Marine engineering​​​​​

Electronic devices

Medical implants​​​​​

Medical implants

Medical Equipment​​​​​

Steel industry

Chemical Processing​​​​​

Chemical Processing

Aerospace and Defense​​​​​

Aerospace and Defense

Energy and Environmental Engineering​​​​​

Energy and Environmental Engineering

Purchasing and Customization

Asking for a price on pure tantalum wire? Include the points below.

  • Material grade (R05200 or R05400)
  • Diameter and tolerance
  • Surface condition and temper
  • Quantity and supply form

For capacitor lines, tell us your winding and payoff requirements. For medical use, mention ASTM F560. Our team will confirm what can be supplied.

Packaging

You can buy wire in coils. It also ships wound on spools, or cut to straight lengths. Your own process decides which form you get. Spools follow DIN standards, and each one is wound with care. Payoff stays smooth on automated capacitor machines.

product-1-1

Element

R05200 (%,Max)

R05400 (%,Max)

C

0.01

0.01

O

0.015

0.03

N

0.01

0.01

H

0.0015

0.0015

Fe

0.01

0.01

Mo

0.02

0.02

Nb

0.1

0.1

Ni

0.01

0.01

Si

0.005

0.005

Ti

0.01

0.01

W

0.05

0.05

Annealing furnace​​​​​ Electron beam furnace​​​​​ Lathes​​​​​ Smelting equipment​​​​​
Lathes​​​​​ Rolling machine​​​​​ Sawing machine​​​​​ Shearing Machine​​​​​

iso certificate

Iso certificate

Packaging​​

Packaging​​

Packaging​​

Packaging​

Packaging​​ Packaging​​ Packaging​​ Packaging​​
Certification​​​​​ Certification​​​​​ Certification​​​​​ Certification​​​​​ Certification​​​​​ Certification​​​​​

FAQ

Q: What is the maximum operating temperature in air?

A: Tantalum oxidizes heavily in air above 300 °C. It also goes brittle when it absorbs nitrogen. For high-temperature service, use vacuum or inert gas.

Q: What separates R05200 from R05400?

A: R05200 is made by electron beam melting. Powder metallurgy is how R05400 gets produced instead. For high-purity drawing, R05200 is usually the grade you need.

Q: Can tantalum wire be welded?

A: Yes. TIG welding works. Electron beam welding works too. Surfaces have to be clean. Argon or helium shielding is needed as well.

Q: What makes tantalum a better pick than stainless steel for sutures?

A: The body does not reject tantalum. It is non-magnetic as well. Implant work uses it. Picking the material and doing the validation still sit with the device manufacturer.

Q: Does spooling affect wire quality?

A: Yes. Poor spooling can change the tension. When wire is wound with precision on DIN spools, the payoff is more even.

Q: A quotation request for this product should contain what?

A: Give the grade and the diameter. Add tolerance, surface condition, and temper. Quantity is needed too.
