Product Overview

Titanium Mesh Sheet, also known as titanium mesh plate or titanium screen, is a precision-engineered product made from high-purity titanium or titanium alloys through punching, stretching, or weaving processes. It combines lightweight strength, superior corrosion resistance, and biocompatibility, making it ideal for filtration, chemical, marine, and medical applications.
At Baoji Chuanglian New Metal Material Co., Ltd., we manufacture and supply a full range of titanium mesh sheets with customized mesh openings, wire diameters, and thicknesses, ensuring optimal performance for industrial and laboratory applications.

Technical Specifications

Property	Specification Range	Available Standard
Material Grade	Gr1, Gr2, Gr3, Gr4, Gr5 (Ti-6Al-4V), Gr7, Gr9	ASTM B265, ASTM B348, ASTM B338
Mesh Type	Woven mesh / Expanded mesh / Perforated mesh	As per design
Mesh Size	2–400 mesh	Customizable
Thickness	0.1–5 mm	Tolerance ±0.05 mm
Wire Diameter	0.1–2.0 mm	As required
Opening Size	0.05–10 mm	Customizable
Surface Finish	Pickled, polished, acid-washed	Optional
Sheet Size	100×100 mm – 1000×2000 mm	Custom size available
Tensile Strength	≥ 350 MPa (Gr2 typical)	Depends on grade

Titanium mesh sheet (expanded mesh, and stamped mesh) is made by expanding and stamping sheet, which is ASTM B265 specified commercial pure titanium sheet. Normal mesh size is 3*6, 5*10, 12.5*4.5, 7*13mm.

Material	Titanium mesh sheet
Weaving	Plain weave, twill weave
Size	Thick:0.8-2.0 mm
	Width:100-300mm
	Length:120-300mm or according to client's design drawing
Feature	1. Developed with advanced foreign technology
	2. Complete use of anodes material, energy saving
	3. Nice electrical conductivity
	4. Welded with precise welding technique
	5. Compact and firm weld crater
	6. Easy to assemble and disassemble of anodes
	7.Perfect control of proportion of anodes and cathodes
Used	Medical, aviation, military, petrochemical engineering, metallurgy, salt-making, textile,sports, sports and so on

Product Features & Benefits

Excellent Corrosion Resistance: Performs exceptionally in acid, alkali, and seawater environments.
High Strength-to-Weight Ratio: Offers durability and rigidity while keeping the mesh lightweight.
Heat and Oxidation Resistance: Retains strength and structure even at elevated temperatures.
Biocompatibility: Non-toxic and safe for medical and food processing applications.
Customizable Design: Available in expanded, woven, or perforated types with tailored mesh openings.
Long Service Life: Superior resistance to rust and wear ensures extended operational lifespan.

Applications

Titanium Mesh Sheets are widely used across various industries, including:

Chemical & Petrochemical: Filters, separators, and catalysts supports.
Marine Engineering: Desalination systems, seawater filtration, and cathodic protection.
Electroplating & Electrolysis: Anode mesh support and electrode substrate.
Medical & Pharmaceutical: Bone implants, surgical instruments, and sterilization baskets.
Aerospace & Automotive: Lightweight components for high-temperature applications.
Environmental Protection: Gas purification, wastewater treatment, and battery recycling.

Be used in a wide range of industries.

Marine engineering

Medical implants

Medical Equipment

Chemical Processing

Aerospace and Defense

Energy and Environmental Engineering

Manufacturing & Process Flow

Our titanium mesh sheets are produced through advanced processes including precision punching, cold rolling, and mesh expansion under strict quality control.
Each step—from raw material selection to final inspection—is carried out under ISO 9001-certified procedures, ensuring dimensional accuracy and consistent performance.
We offer multiple mesh fabrication types: expanded titanium mesh, woven titanium mesh, and perforated titanium plates, all with precise aperture uniformity.

Raw material inspection

Titanium Melting

Titanium forging

Machining and forming

Final inspection

Packaging

Quality Control & Inspection

100% Material traceability with mill test certificate (EN 10204 3.1).
Dimensional inspection and visual surface checks.
Ultrasonic and eddy current non-destructive testing (NDT).
Complies with ASTM, ISO, and GB/T standards.
Third-party testing (SGS, BV, or TUV) available upon request.

ISO 9001:2015

Customization & OEM Services

We provide OEM and ODM services for all titanium mesh types, including mesh shape design, surface treatment, and frame assembly.
Our engineers assist in optimizing specifications based on application needs—whether for industrial filtration, electrolytic cells, or biomedical devices.

Packaging & Global Logistics

Each titanium mesh sheet is securely packaged to prevent deformation and contamination:

Inner plastic wrap or kraft paper for surface protection.
Outer export-grade wooden case with foam padding.
Moisture-resistant vacuum sealing for long-distance shipments.
We deliver globally through air, sea, or express services with full export documentation support.

Feedback from customers

Titanium Rod For Sale

Why Choose Us

18+ years of experience in titanium material production.
Located in Baoji, China’s Titanium Valley, ensuring stable raw material supply.
Fast delivery and competitive pricing for bulk orders.
Customized mesh design and surface finish options.
Strong technical support and one-stop service from design to export.

Certification

FAQs

Q1: What’s the difference between expanded and woven titanium mesh?
A1: Expanded mesh is cut and stretched from a titanium sheet, offering high strength, while woven mesh is made from interlaced titanium wires, providing flexibility.

Q2: Can titanium mesh be welded or formed?
A2: Yes. Titanium mesh can be TIG-welded or shaped depending on the mesh thickness and type.

Q3: What mesh opening size should I choose?
A3: It depends on the application—smaller openings are ideal for fine filtration, while larger ones suit structural or support purposes.

Q4: How long is the delivery time?
A4: Standard sizes ship within 7–15 days, while custom orders may take 20–25 days depending on specifications.

Q5: Do you provide test certificates?
A5: Yes, we supply material composition reports, mechanical property data, and third-party inspection certificates upon request.
